Makor Q-One 1300 with Pumps and Guns & Infeed/Outfeed Conveyor

CALL FOR AVAILABILITY

Great Condition!!

1 paper roll included

System Description:

INCLUDES BELTED INFEED AND OUTFEED CONVEYORS

Spraying enclosure pressurized with filtered air via two intake fans

Internal air flow is adjustable by means of inverters

Paper feeding and re-wind are at opposite ends of the machine for easy access

Paper re-rewinding has a self-adjusting spreader to keep paper flat and evenly wound

Vacuum bed under paper conveyor has an independent blower

Touch screen PLC controller includes spraying recipes and production statistics

Guns & Pumps:

(2) Kremlin Pumps

 (4) Kremlin  Gun / Makor

 Kremlin Fluid Regulator3

Standard Features:

Feed Motor Power;         0.75 KW

Exhaust Fan;           5.5 KW

Reciprocating Motor;       2.2 KW

Paper Rewind Motor;      0.18 KW

Vacuum Belt Motor;    1.5 KW

Feed Speed (feet);      3 - 20 f/min

Working Speed; 8 - 16 f/min

Paper Roll Diameter;    21.5"

Weight;  7,800 lbs.

Extraction Air;    7950 cfm

Pressurization Air;        3900 x 2 cfm

Full Load Amps;                48A

Total Installed Power;    13 KW

The Q-ONE is a single arm oscillating spray machine utilizing 4 automatic spray guns. It is designed for finishing medium to small lots where frequent product changes or intermittent spraying is required. Q-ONE is also ideal for use when spraying glue or very fast-drying coatings. The conveyor is a self-winding disposable paper roll that eliminates the necessity for a belt cleaning system and the need to clean the machine between jobs. Simply flush the guns in preparation for the next batch of parts.
