Northtech 10hp Spindle Shaper

10hp variable speed shaper table. Machinery Associates is a full line Northtech Dealer.

MA ID: SHM - 13278
Price: Call For Price
Category:

Manual Single/double Shapers

Manufacturer: Northtech
Model: NT 880HSK-1032
Condition: New
Electric: 230 Voltage 60 Cycle 3 Phase
Northtech Shaper

Specifications:

10hp variable speed (3,000 – 13,350rpm) inverter controlled spindle

Spindle motor is rotation reversible with electronic braking

1x    1-1/4'' x 4” HSK-63F spindle included

HSK-63F quick change spindle release system developed by Andi CNC Machining Centers

Spindle tolerance of .0001" *

Includes sensor light to ensure proper mating of the chucks as well as correct full pneumatic pressure for safety

Moveable overarm control panel

35" Ergonomically designed precision milled cast iron table

Jack Screw / Quill Housing elevation adjustment with 1hp motor

Electronics = CE Approved Components

Dual Voltage = 230/460 Volt

Control Voltage = 110 Volt

Programmable Elevation with Digital Display

Operator Panel = Adjustable Operator Panel

Pass-Line = 35''

Dust Collection = (1) 4'' (1) 5'' @ 1117 CFM

FLR Included = Filter, Lubricator, Regulater

Recommended CFM = 1/4'' Line @ 90 PSI

Emergency Stop = Push Button

Fence Type = Adjustable

Fence Dims. = (2) 5-1/2'' x 24''

Micro Fence = Micro Adjustable

Worktable Dims. = 61'' x 38'' x 35''

Measure Method is by Precision Encoder

Decible Rating = 80 dB

Warranty is one year parts

All machines are tested stateside prior to shipment providing trouble free start up.

OPTIONS:
460V 3PH electrics
Sliding table
880 Optional NC Control Systems for fences
Optional 1-1/4” HSK chuck 2” under nut
15hp motor in lieu of 10hp
Optional 40mm HSK chuck 2” under nut
Optional 50mm HSK chuck 2” under nut
Router spindle HSK chucks 1/2”, 5/8”, 3/4” capacity


Shipping Footprint: 68 (length) x 48 (width) x 75 (height)
Weight: 2000 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
