Alfa T300 Automatica Vertical Miter Saw

2011 Alfa T300 Automatica Automatic Vertical Miter Saw Cutting Process Machine

MA ID: SCM - 13195
Price: $16,000.00
Category:

Cutoff/Miter/Toe Notchers

Manufacturer: Other manufacturer
Model: T300
Year of Manufacture: 2011
Condition: Very Good
Electric: 230 Voltage 60 Cycle 3 Phase
Alfa Vertical Miter Saw

Specifications:

High speed cutting to produce up to 500 frames per hour (based on 100 x 150mm frames.)

For 45 degrees cuts on picture frames, doors, windows and furniture profiles.

Min external size 110mm

Max external size 1150mm

Max width 50mm

Max height 55mm

2 x 1.5kw saw motors

300mm max blade diameter

Horizontal hopper feed unit to hold approx. 20 lengths

Windows based color touch screen controller with RS232 / USB connections
Software to memorize over 5000 programs

4 different cut sizes per program to optimize cuts and reduce scrap

Outfeed belt conveyor for cut pieces

Step #1 – Vertical Material Feeder

Step #2 – Material Loading – Material is automatically loaded to be cut from the feeder.

Step #3 – A Material Gripper System is used to provide molding part movement into the Saw Cutting Station

Step #4 – Double Miter Saw Cutting – Double Miter Cutting – Equipped with a Speed Feed Servo System, the TA-300 has a production output range from 1,500 to 1,900 cut pieces per hour. A Vertical and Horizontal Clamping System within the cutting station firmly holes the molding during the cutting process.

Step #5 – Part Unloading Belt – Belt allows the removal of Cut Pieces (and division of those pieces….meaning sending one part one way and the other part elsewhere)

Equipped with “Part Present” Photocell
Kicks Cut Pieces to Pneumatic Conveyor Belt for Step #6 of the process




Shipping Footprint: 12 (length) x 12 (width) x 5 (height)
Weight: 2000 lbs
