Maksiwa BMP.3200.IR Sliding Table Saw

NEW! with a 7.5HP main motor and ¾ HP Scoring motor (3 phase)

MA ID: PSS - 13463
Price: $12,000.00
Category:

Panel Saw - Sliding

Manufacturer: Other manufacturer
Model: BMP.3200.IR
Year of Manufacture: 2024
Condition: New
Electric: 220 Voltage 60 Cycle 3 Phase
Maksiwa Sliding Table Saw

Specifications:

Sliding table dimension 126” x 15 ½” – 3200 x 360 mm
Cast Iron fixed table 21.6” x 35.3” / 896 x 548 mm
Extension table (rear) 37 ½” / 952 x 896 mm
Extension table (front) 12.6” x 32.7” / 830 x 320 mm
Main saw blade (Max.) 305 mm
Main saw bore 30 mm
Max. cutting height at 90 (355 mm) 4 13” / 90 mm
Max. cutting height at 45 (355 mm) 2 3/4” / 63 mm
Main motor power 7.5 HP (3 ph)
Main blade speed 4000 rpm
Scoring saw blade 120 mm
Scoring saw blade bore 20 mm
Scoring blade motor power 3/4 HP (0.56 kw)
Scoring blade speed 8000 rpm
Cutting width 1,300 mm
Main saw blade tilting adjustment Manual (0 ~ 45°)
Main saw blade tilting adjustment Manual
Dust collection system (For overhead guard) 4.72” 120/ 64 mm (120/100 mm)

Main blade arbor size 1 3/16” (30 mm)
Scoring blade arbor size 3/4” (20 mm)
Max tilt 45°
Max depth cut 3 15/16”
Max cutting length 120”
Warranty 2 years


Shipping Footprint: 192 (length) x 280 (width) x 65 (height)
Weight: 2500 lbs
