2021 Superfici MINI “PLUS” AUTOMATIC SPRAY MACHINE w/ Laminar 7.5M Dryer

Very little use on this machine. Purchased to start new division and never took hold of the market.

MA ID:	FLA - 13907
Price:	$170,000.00
Category:	Systems & Automated Lines
Manufacturer:	Superfici
Model:	Mini Plus W/ Laminar 7.5 Dryer
Year of Manufacture:	2021
Condition:	Excellent
Electric:	480 Voltage 60 Cycle 3 Phase
call for availability Machine Decription: Working width 1300 mm Max. work-piece thickness 120 mm Working table height 900 +/- 20 mm Feed speed 1-3 m/minCompressed air consumption approx. 1800 Nl/min. (With 4 airmix guns) Exhaust air volume 8000 m3/H Infeed roller conveyor length 676 mm Outfeed roller conveyor length 707 mm Total machine length 3533 mm PLC extension to control the valves Software upgrade with user friendly HMI for the control of the automatic sequence of the color change 10” HMI Touchscreen In-feed and out-feed driven roller conveyor system Central belt conveyor with protective paper device 3 circuits with manual L ported valves (can recirculate manually via the L ported valve) + 1 flush circuit 4 air-assisted airless or airless guns complete, with 1 set 12-174 nozzles (Kremlin AVX) Connection piping for 3 circuits & solvent flush 3 high pressure pump, able to feed up simultaneously 4 spray guns, with air regulator, air pressure gage, fluid filter, and 5-gallon suction tube (Kremlin 20C100T) 3 fluid pressure regulators with gages, 1 for each 20-50T pump 3 manual L ported valves 1 flush pump, 10-25 Kremlin, with 5-gallon pick up rod 1 Superfici pump stand 3 closed loop material circuits (6 hoses) for 3 different coating materials 1 open end circuit (1 hose) for cleaning agent (solvent flush) 4 automatic color change valves, controlled by 4 solenoid valves, mounted on the reciprocator arm (3 colors + flush) Laminar Dryer 7.5M Coveyor Driven belt Air System for fume Removal 40KW Electiral Heating Coils for Drying

All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
