Brandt Ambition 1110 Edgebander
Clean, small shop machine WITH PREMILL ready to go!!
| MA ID: | EBS - 14322 |
| Price: | Call For Price |
| Category: |
Edgebanders -Single Sided |
| Manufacturer: | Brandt |
| Model: | Ambition 1110 (KDF110) |
| Year of Manufacture: | 2015 |
| Condition: | Very Good |
| Electric: | 230 Voltage 60 Cycle 3 Phase |
|
2015 Brandt Ambition 1110 Edgebander
Technical Specifications: 016″ to 1/8″ maximum edgebanding thickness capacity (coil or strip) Edgeband length: strips minimum 5/16" min. to 2" max. panel thickness Minimum panel length: 5-1/2" Minimum panel width: 2-3/4" Edgeband height: 5/16 to 1-5/8" Electronic Easy Control with backlit LCD display (2) 1 HP 12 000 RPM pre-milling units with diamond cutterheads Automatic magazine for strip and coil feeding Hot melt glue pot with 12 minute heat up time Automatic temperature reduction feature (lowers the glue temperature if no panel Guillotine for cutting up to 3 mm PVC from the coil Pressure station with (1) motorized pressure roller plus (2) additional idle 1/4 HP 12 000 RPM double motor end trim .33hp 12 000 RPM top and bottom trim station equipped with two DFC combination Top and bottom profile quick change scraping unit Finish scraping unit 3/4 HP 1-speed feed with speed of 26 FPM Digital on top pressure beam for height indication Adjustable infeed fence with digital readout Automatic height adjustment with top Digitals on top and bottom trim station Dust extraction: (4) 80 mm outlets and (1) 100 mm outlet 1600 CFM required Compressed air connection: 6 bar (85 psi) Isolation transformer with variable |
|
| Shipping Footprint: | 12 (length) x 4 (width) x 5 (height) |
| Weight: | 2000 lbs |
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
