BAM CNC-MFSR 5-Axis CNC Stair Machine

NEW! CNC 5 Axis! With a one year Warranty! One year lead time.

MA ID: DSS - 13755
Price: Call For Price
Category:

Door & Stair Shapers

Manufacturer: Bam
Model: CNC-MFSR
Condition: New
Electric: 230 Voltage 60 Cycle 3 Phase
BAM CNC Stair Router

Specifications:

  • Fully programmable CNC 5-axis servo driven machine.
    X Axis
    Y Axis
    Top Z Axis (top router depth control)
    Bottom Z Axis (bottom router depth control)
    A Axis (advancing of board)

Programmable Touch Screen for simple stair characteristic input by operator

Programmable Touch Screen for landing cut both
top & bottom for open, box, and contemporary stair profiles

Two (2) high frequency routers with 7.5 HP/24,000 RPM fan-cooled spindles that can accommodate shanks of ½” or 5/8″ diameter

Accepts one or two stringers at a time – ¾”, 1″ or 1- ½” thick for a total of 3″ maximum thickness and 7- ¾” to 15- ¾” wide

Extra wide ¾” guide rails for more bearing surface with a 3- ¼” high fence

Five (5) cylinder clamps – 3 fixed and 2 adjustable – for up to 2,950 pounds of vertical stringer clamping force with an additional 1,180 pounds of horizontal clamping force, for a total of 4,130 pounds of force holding the stringer in place

Self-centering feed system on linear bearings for better support and elimination of wear on the brass parts

Dust collection cups on each router for clean, efficient operation. Air requirements 110psi at 15cfm (minimum ¾” diameter unrestricted line)

Accommodates staircase angles from 20 degrees to 45 degrees and riser kickback from 5 degrees to 11 degrees with landing cut

Cuts up to ½” deep in yellow pine at the maximum rate of 20″ per second and an open stringer in a single cut

Programmable to cut any combination of box, contemporary, or open stairs including landing cuts

Completes the top and bottom landing cut without additional handling or manual sawing

Adjustable settings for wedge fit or material variances

Comes with manufacturer’s standard 1 year warranty


Shipping Footprint: 8 (length) x 7 (width) x 7 (height)
Weight: 3500 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
