Diehl SL-52 Straight Line Rip Saw

Diehl SL-52 Straight Line Rip Saw Excellent Condition!

MA ID: RSL - 13245
Price: $24,000.00

Rip Saw - Single (straightline)

Manufacturer: Diehl
Model: SL-52
Condition: Excellent
Electric: 230 Voltage 60 Cycle 3 Phase
Hours on meter: LOW HOURS!!!!
Diehl Straight Line Rip Saw


15HP Motor (w/motor brake), 3,600 RPM belt driven, fixed 2″ arbor.– 14″ to 18″ Blade diameter.

4-1/4″ max. thickness with an 18″ blade diameter.

2 HP – 1,800 RPM feed drive, variable feed speed 65 to 190 FPM.

25″ Throat depth to right of blade, 25″ of table to left of blade.

Table size 78″ X 64″
Equipped with & Features:– Cast iron pressure bar arms with ball bearing rollers.

Adjustable rip fence.

Self-adjusting anti-kickback fingers with control cam.

Automatic lubrication of feed chain & race.

Full overload and under voltage protection.

Manual arbor brake for safety with interlock; 34″.


Shipping Footprint: 8 (length) x 7 (width) x 6 (height)
Weight: 5200 lbs
