Northtech NT-24-15HCVS-XL Ultimate 24" Planer

NEW! Northtech 24" Planer With A 24" Helical Head. Machinery Associates is a full line Northtech Dealer.

MA ID: P1S - 13110
Price: Call For Price

Planers - Single Sided

Manufacturer: Northtech
Model: NT-24-15HCVS-XL
Condition: New
Electric: 230 Voltage 60 Cycle 3 Phase
Northtech Planer



Cutterhead motor: 15HP, 3PH 230V 60HZ 5300RPM

Power table motor: 1HP

Feed drive motor: 1HP



Stocking thickness range: 3/16" - 7-3/4"

Max depth of cut: 5mm (3/16")

Max. width of stock: 610mm (24")

Cutterhead diameter: 80mm (3-1/4")



24" Helical Head with (6) rows of 15 x 15 x 2.5mm 4-way carbide inserts.

Spiral cutterhead provides high chip removal rate, superior surface finish at low noise levels.

Range of feed speed: 0-75 ft./min. variable inverter.

Quick adjust bed rollers

Powered table elevation for fast and convenient thickness setting via the digital control.

Extra heavy rib reinforced cast iron table with precision ground surface.

Corrugated sectional infeed roller has independent sections for running strip stock of varying thickness.

Table area: 25" x 27-1/4" (635 x 692mm)

Amperage requirements: 230V/460V 39A/18A

(1) 6" Dust port requiring 981 CFM @ point of extraction

(1) Tool box

Warranty is one year parts

Voltage change Add . . . $ 420.00
Optional 1PH 220V 7.5HP motor Add . . . $ 425.00

Shipping Footprint: 43 (length) x 45 (width) x 55 (height)
Weight: 1700 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
