LEADERMAC LMC 633 13" WIDE MOULDER THRU FEED
LEADERMAC LMC 633 13" WIDE MOULDER THRU FEED
| MA ID: | MFT - 12971 |
| Status: | Sold |
| Price: | $45,500.00 |
| Category: |
Moulder - Feed Through |
| Manufacturer: | Leadermac |
| Model: | LMC 633 |
| Year of Manufacture: | 2007 |
| Condition: | Good |
| Electric: | 460 Voltage 60 Cycle 3 Phase |
|
NEED A 12 INCH WIDE MACHINE FOR s4s AND PROFILING, THEN ADD 1" AND DO STAIR TREADS. GOOD CONDITION READY FOR SHIPMENT.
Working dimensions: 13" x 6" (Ideal for stair treads).Spindle configuration: B-R-L-T-T-B Motors: Bottom -15HP, Right -15 HP, Left - 15HP, Top 20 HP and Top 20 HP and Bottom -20 HP.Spindles: Dia. 1-13/16” at 7,200 RPM’s with mechanical readouts all spindles. "QUIK TRUSET' for setting of left and top spindles. left and top spindles. Includes pneumatic chipbreakers and pressure elements. Vertical spindle travel 3.17" up/down. Outboard bearings on spindles 1,4,5 and 6.Feed: VFD speed from 20-120 FPM; 10 HP motor. operation. (11) top powered feed rollers. Powered table rollers (5), roller prior to first bottom serrated. Short stock attachment.Tables: Infeed table 4'-0" with side pressure roller; chromed tables, fences and chipbreakers. Manual table lubrication pump. Central lubrication ports.Includes: Additional rollers, cutterheads and manuals. |
|
| Shipping Footprint: | 22 (length) x 7 (width) x 7 (height) |
| Weight: | 16000 lbs |
