DMC EUROSAND L53 WIDE BELT SANDER 3 HEAD

DMC EUROSAND L53 WIDE BELT SANDER 3 HEAD

MA ID: SWM - 12955
Status: Sold
Price: $69,000.00
Category:

Wide belt and drum (Multi contact)

Manufacturer: DMC
Model: L53
Year of Manufacture: 2011
Condition: Good
Electric: 460 Voltage 60 Cycle 3 Phase
GREAT CONDITION WIDE BELT SANDER 3 HEAD WIT 53" WORKING WIDTH. OR FINE SANDING

Working width: Max. 53' wide with working height 3/16" to 6-3/4". With automatic thickness adjustment,

Head configuration: 1st head - steel contact roller spirally grooved 9.8" diameter. 35 HP with pneumatic grid compensation. ; 2nd head - Rubber Contact Roller, spirally grooved, approx. 85° Shore hardness,  9.8" dia. 30 HP motor. Pneumatic operated grit compensation. 3rd head - "Superfinishing" Segmented Polishing Platen with inner Chevron belt.  "PE 45 EPICS" (Electronic Pad Independent Control Stroke) - electronically controlled, segmented pressure pad with (45) pneumatically activated segments, each 30 mm (1.2") wide. This system allows imperfections in the panel up to 1/16". Driven by 2-speed motor 20 / 25 HP motor. All heads use abrasive style belts 103" x 54". Belt tracking and pneumatic tensioning.

Feed system: 35-7/16" Constant pass line height, Vacuum bed assembly to ensure flatness of parts and feeding of small panels. Variable feed speed 13 - 62 FPM with 10 HP feed motor.

Controls: Pneumatically operated conveyor belt tracking. Hold down shoes for the first three heads, rubberized rollers in the platen area. Front-mounted control console, E "HYDRA V-PAD" 17" color touch-screen monitor. NC-computer control and management of all machine functions. Storage capacity for (120) different sanding programs. \n\n-- Sanding heads with computer setup and adjustment, light indication of panel movement, thickness, and features maintenance indicator. Oversized parts and infeed protection.

Includes: Dust collection manifold.


Shipping Footprint: 12 (length) x 8 (width) x 7 (height)
Weight: 9000 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
