Busellato Jet2

Working Field:

• X axis 120" (3,050mm)
• Y axis 49.2" (1,250mm)
• Z axis stroke 6.7" (170mm)

Positioning Speeds:

• X axis  197 ft/min  (60 m/min)
• Y axis   197 ft/min  (60 m/min)
• Z axis   66 ft/min  (20 m/min)

Motion system utilizes rack & pinion and precision ball screws driven by AC servo motors

The working head travels on high precision profile guide rail & way bearing system.

Work Table:

6 support rails with 4 panel lifters for heavy panels and 3 pods per rail.

Boring Unit:

3 Hp (2.2 kW) 4,000 RPM motor, 12 independent vertical spindles (7 in X, 5 in Y), 6 horizontal spindles (2+2) in X and (1+1) in Y.

(1) X axis grooving saw that will accept a 120mm diameter blade

Machining:

(1) 10 Hp (7.5 kW) electro spindle with ISO 30 adaptor; variable spindle speed from 1,000 - 18,000 RPM

Operator and Machine Control:

PC interface with TPA Genesis Evolution 2.2 operating in MS/Windows 2000 operating system.

15 inch color monitor, international keyboard, soft touch keypad and industrial mouse, 4 serial ports, 1 parallel port, 2 USB ports, 1 1.44 floppy drive and 1 CD ROM drive

Complete with:

All manuals, vacuum pump, safety mats, safety hood, and back up disks.
