RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW

RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW

MA ID: RGR - 12805
Status: Sold
Price: Call For Price
Category:

Rip Saw - Gang (multi blade)

Manufacturer: Raimann
Model: KM3102M/VALURIP "COMPACT"
Year of Manufacture: 2019
Condition: Very Good
Electric: 460 Voltage 60 Cycle 3 Phase
Hours on meter: VERY LOW
GREAT OPPORTUNITY ON A SAW PACKAGE FOR RIPPING AND CUT SOLUTIONS WITH 16 POINTS OF MEASUREMENT.

Less than 100 hours on this machine!!!!

Raimann Valurip Compact

Working dims:  Length 40" to 160"; width 4" to 12" and thickness 3/4" to 3" for hardwood or softwood rippings.

Cutting dims: Width min. 5/8" (1st movable blade); min. 1-5/8" to 10-1/4" (2nd movable blade) and fixed pocket 1". Production in auto mode 7 x 10' boards per minute.

Feed: Boards are manually placed on the infeed conveyor cross chains. once infeed is clear of previous board the chains lift up and feed board to positioning fence. (16) points of measurement are taken and optimizing solution of board data positions saw blades on saw for optimum cuts. Operator has option to manually override with joy stick positioning of the board.

Raimann Variorip KM 310 2M

Saw: 50 HP motor with arbor dimension of 2.6"; RPM of 4200. Quick fix arbor (hand turn nut) for positions blades. Saw blade dia. 12" to 14". Blade positions by ball screw adjustment.

Chain: Width 12-3/4" steel chain with every 3rd link with spikes. Automatic oiler for chain lubrication. Chain has autoshutoff when oil level is low. Roto chain brush for continuous chain cleaning of debris. (4) set of antikickback fingers.

Feed: Variable 30-150 FPM with 3 HP motor.

Controller: Raimann Proficut Direct (Office Version), with 15" color screen with storage for 100 cutlists, production recording and yield.



Note: Photos to follow with video


Weight: 8500 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
Click Herefor More Info or call Product Manager Gary Carney 877-622-4657 x101
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW
RAIMANN VARIORIP KM310 2M WITH VALURIP "COMPACT" MULTIBLADE GANG RIP SAW

2019 Raimann Variorip KM310
