RAIMANN KM US BV - 1 MOVING BLADE GANG RIP SAW

Great condition, small shop, moderate use.

MA ID: RGR - 13923
Price: $36,000.00
Category:

Rip Saw - Gang (multi blade)

Manufacturer: Raimann
Model: KM US BV
Year of Manufacture: 2001
Condition: Good
Electric: 460 Voltage 60 Cycle 3 Phase

Saw: Working dimension up to 12-1/4" WIDTH  X 3.5" HEIGHT.

Arbor: "QUICK FIX" arbor for fast changeovers. Diameter 2-1/2" hydraulic QF set up for saw change. Saw dia. range  10" to 14-7/8". Equipped with 12" x 2.5" blades.

Movable Blade: 1 via foot pedal control

Fixed Blades: 2

Lasers: (4) 15 mw laser lights.

Motor: 50 HP V belt drive; with cutting shaft set at 4,200 RPM. (4) sets of antikick back protection -- 2/2.

Includes: Tools, collars and blades as pictured.

Quick Fix System: combines fixed blades mounted to individual collars that slide back and forth on the arbor into position, then lock into place, tightening the "Quick fix"nut on the arbor. Tool and spacer free!
Hold-down: 20" on center located between the upper hold-down rollers (a replaceable wood hold-down shoe plate is
not included)Other Features: - Automatic starting
- 6" throat depth - 3/4" min. strip width
- 21" min. stock length.
- Feed system
16 - 110 FPM variable speed
- Infeed fence: Adjustable
- Infeed extension with an additional bed roll
- Infeed over thickness shutoff protection - 1.2 HP feed drive motor
- Spike plates located on every 3rd link
- C
hain lubrication: Automatic
- Top & bottom anti-kickback fingers (2 sets)
- Dust hood:
8" Diameter

Shipping Footprint: 68" (length) x 68" (width) x 60" (height)
Weight: 4000 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
Click Herefor More Info or call Product Manager Gary Carney 877-622-4657 x101
RAIMANN KM US BV - 1 MOVING BLADE GANG RIP SAW
RAIMANN KM US BV - 1 MOVING BLADE GANG RIP SAW
RAIMANN KM US BV - 1 MOVING BLADE GANG RIP SAW

Raimann KM US BV-1 Moving Blade Gang Rip Saw


Location: Midwest Midwest
