14 INCH ROTARY AIR LOCK
MA ID: | DCB - 2096 |
Status: | Sold |
Price: | $1,950.00 |
Category: |
Blowers / Fans / Airlocks |
Manufacturer: | Koger |
Model: | 14-2-Q32 |
Year of Manufacture: | 1998 |
Condition: | Good |
14 inch opening, , no motor Maintains operating air pressure and control of pneumatic material conveying system; most effective in low-pressure industrial applications. Roller chain and sprocket driven by a parallel shaft reducer with 2 HP, 3-phase, 60 hertz, 230/460 volt motor. Protective chain guard is constructed with an expanded metal front for easy visibility of chain operation. C-flange motor mount permits positive drive for more torque and increased efficiency. Variable metering speeds Six-blade rotors are designed to meter larger foreign objects. 10-gauge HR housing formed to precision tolerances with smooth interior surface to assure free flow of materials. Round inlet and outlet flanges are pre-drilled with 7/16" bolt holes for quick and easy installation. Available with matching flanges. Easy service access to rotor through removable side plates. |
|
Shipping Footprint: | 4 (length) x 4 (width) x 3 (height) |
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
