DIMTER OPTICUT S90 OPTIMIZING CROSSCUT SAW WITH 12" WIDTH CAPACITY
DIMTER OPTICUT S90 OPTIMIZING SAW WITH 12" WIDTH CAPACITY, LATERAL INFEED AND OUTFEED WITH (2) KICKERS
|MA ID:||OSS - 13708|
|Price:||Call For Price|
Optimizing Saws and Stop Systems
|Year of Manufacture:||2011|
|Electric:||460 Voltage 60 Cycle 3 Phase|
GREAT PUSH FEED SAW WITH 12" WORKING WIDTH, GOOD CONDITION WITH INFEED AND OUTFEED.
Working dimensions: Width 1 5/8″ to 11 3/4″; thickness 5/8″ to 3 7/8″ and length 2′ 11 3/8″ to 20′ 8″ (6.3M).
Motor: 10 HP saw motor at 4,800 RPM. with 20" saw blade.
Feed: Variable speed up to 750 FPM with return up to 590 FPM.
Pusher: Automatic pusher arm controlled by servo motor that travels the length of the board measuring: length, grade zones, and defects. Positioning accuracy to +/- 1 mm. Swiveling positioning pusher with photo eye for automatic length detection.
Software: OPTICOM DIRECT control system with 12" color "touch" screen. Controls for: maximum yield, maximum value, quantity of pieces, diagnostics. (100) board groups with (8) grades. Auto width measuring. Ethernet connection.
MATERIAL HANDLING; LCF infeed with direct feed into the saw; Sort line: Driven by a 2 hp motor with outfeed belt 10" x 45' with (2) mechanical kickers for sorting as inputted from the OPTICOM DIRECT.
