L & L DA-100 HF GLUE PRESS FOR PANELS

L & L DA-100 HF GLUE PRESS FOR PANELS RECONDITIONED

MA ID:	PRH - 13169
Status:	Sold
Price:	$19,500.00
Category:	Presses - Hot
Manufacturer:	L&L
Model:	DA-100
Year of Manufacture:	2000
Condition:	Very Good
Electric:	460 Voltage 60 Cycle 3 Phase
GREAT OPPORTUNITY FOR PRESSING PANELS BY A WELL KNOWN BRAND OF MACHINERY. Working dimensions: 50 x 100 in. platen size (clamping area), pneumatic 4-way pressure (side/edge and end) high frequency assembly press; 48 x 96 in. curing area, 4 in. thickness cap., hydraulic cylinders on side and top w/ 4 in. bore x 4-1/4 in. stroke and 6-5/16 in. centers, 15 kW generator that cures approx/ 1,500 sq. in. of glue line per min. push button electrical interface.
Shipping Footprint:	20 (length) x 7 (width) x 7 (height)
Weight:	4500 lbs

All Information including Photos and Videos are supplied by a 3rd party Source.
Some photos may show tooling. Tooling is never included in the listing unless otherwise noted in the description.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
