Hoffmann PP2-NC Automatic Dovetail Routing Machine NEW!

A CNC Controlled Dovetail Cutting Machine. Programmable to join anything you need!!

MA ID: DV - 12280
Status: Archived
Price: $24,500.00
Category:

Dovetail Machinery

Manufacturer: Hoffmann
Model: PP2-NC
Year of Manufacture: 2011
Condition: Excellent
Electric: 230 Voltage 60 Cycle 3 Phase
Hoffmann PP2-NC Programmable Dovetail Joinery Cutting Machine

This machine has been in storage for it's entire life. It is in new condition....being sold as used machine.  If you need this, you will never find one, certainly in this condition.

Overview

Hoffmann PP2-NC is a versatile, numerically controlled routing and drilling machine for the production of frame and sash joints in windows and doors, overhead glazing systems, curtain walls, sunrooms, conservatories as well as handrails, custom trim moulding and other larger dimension stock. Dovetail keyways are routed and dowel holes are drilled in one machining cycle.

Keyways can be routed from left to right, right to left, bottom to top and top to bottom or any combination thereof. Dowel hole locations are programmable across a wide range of parameters.

Miter joints from 0 – 67.5 degrees as well as 90 degree square joints can be processed with ease – custom fence plates and fixtures are available per customers’ requirements.

Quality Construction with hardened ball and screw drive and NC stepper motor

The motors brackets are mounted on a precision ball-and-screw spindle for fast and accurate lateral positioning via servo motor. The routing height (upward travel of router motors) is also electronically controlled to within 0.5mm.

Fully programmable for wide range of profile dimensions

All relevant data is entered either directly on a color touch-screen or downloaded via USB port. Up to 100 different routing and drilling programs can be saved for quick retrieval.

Two workpieces are placed on the machine table and processed simultaneously for dovetail keyways and/or dowel holes.

Increased productivity and quality from perfectly aligned dovetail keyways

Being able to program dovetail keyway and dowel hole locations and and storing the data with a customer defined file name, e.g "Shutter Z-frame, large" or "Nantucket Mirror Frame" allows for quick and reliable recall and assures every pieces of moulding has Hoffmann Keyways and dowel holes placed in exactly the same locations. this assures perfectly aligned and tight miters every time.

Plantation Shutter Manufacturing

For Plantation Shutter Operations we offer optional support blocks for various Z-Frame Moulding. These precision-machined aluminum support blocks are manufactured to customers' specifications to match their profiles perfectly We also offer additional horizontal hold-down clamps to secure difficult to machine profiles.

Hoffmann PP2-NC Technical Data                       .

Power supply220 volts, 18 A., 3 ph
Motor size    2 x 1,000 watt
Motor speed33,000 rpm
Compressed Air Supply90 psi
Router Collet Size1/4"
Max. material width5"
Max. material height5"
Max. routing height4"
Number of Keyway locationsup to 3 per miter
Number of different Keyway lengthsup to 3 per miter
Supplied router bitsW-2 solid carbide
Available router bitsW-1, W-2, W-3
Dust collection port4" diameter
Approx. net weight528 lbs.

Shipping Footprint: 4 (length) x 4 (width) x 5 (height)
Weight: 550 lbs
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
