Profilematic Moulding Profile Sander (3 head)
Model 503 - Fully Reconditioned
| MA ID: | SPM - 10600 |
| Price: | $13,900.00 |
| Category: |
Profile/MouldingSand/Denib/Clean |
| Manufacturer: | Profilematic |
| Model: | 503 |
| Condition: | Very Good |
| Electric: | 240 Voltage 60 Cycle 3 Phase |
|
Profilematic #503 3 Head Moulding Profile Sander Completely refurbished 3 x VPS vibrating air-loaded sanding units 5HP vibrating motor for each head 2 x pneumatic cylinders for each sanding head providing sanding pressure control and ½” stroke oscillation Dust protected round guides Variable speed vibration from 200 - 1,800 RPM Head position adjustment range of 120° for profile matching Equipped with air blower nozzles for auto cleaning workpiece & sandpaper Part feeding by 4.5” wide grip coated conveyor belt system Quick adjustment hold-down wheels & fence system Feed speed variable 0 - 35FPM 0.25HP DC gear drive Forward & reverse feed mode Dedicated control for each sanding head Manual raise and lower of sanding pressure and vibration speed Profile width from ~ 0.5” to 4" 5” max material feed thickness 10” max width with support fences |
|
| Shipping Footprint: | 98 (length) x 30 (width) x 40 (height) |
| Weight: | 3200 lbs |
Please confirm all data before committing to a purchase.
