NORTHTECH EM 250 LINEAR END MATCHER

NORTHTECH EM 250 LINEAR END MATCHER

MA ID: FJ M-11685
Price: $44,900.00 -or- as low as $907.43/mo.*
General Location: Midwest
Category:

Finger Jointers and End Matchers

Manufacturer: Northtech
Model: EM 250
Year of Manufacture: 2018
Condition: New
Electric 230 volt, 60 cycle, 3 phase
Great price on a through feed linear endmatcher with tooling and roller infeed and outfeed.



Working dimensions: Width 1-1/2" x 10"; thickness 3/8" to 1.3/8"; length random length up to (32 lbs) and minimum length 11".

Spindles: (2) 5 HP motors for end cuts; 40 mm dia. with 7,400 RPM; dual lineal shaft guides for accurate head movement.

Feed: 1 HP with speed up from 80-400 FPM; PLC controlled feed system manages spindle position, part location and both infeed and outfeed tables.  Touch Screen interface with productions tracking.

Tables: Chromed; 134" powered infeed and 88" outfeed; clamping system at infeed and outfeed; (3) spring loaded bed rollers.

Includes: (1) set of insert tooling  for tongue and groove. Tool box with set up tools.

Note: Processing speed of 75 FPM based on 6' material length. Warranty (1) year. NEW Never used.





Shipping Footprint: 89" (length) x 52" (width) x 62" (height)
Weight: 2300 lbs
Rigger: Not Required
All Information including Photos and Videos are supplied by a 3rd party Source.
Please confirm all data before committing to a purchase.
*Subject to credit approval. Additional programs available.
